DySC Benifits
· 100% sag protection
· SEMI F47 compliance
· Extremely scalable from 0.25 kVA to 2000 kVA
· Relatively compact size
· Highest energy efficiency (>99%)
· No batteries to replace
· No flywheel bearings to wear out
· No compressors or pumps
· No need for air conditioning or special ventilation
DySC Protection Features
· Proprietary “Double Conversion” Power Core–dCPC
· Fastest Sag Detection and Response Time
o - DySC
is optimized for fast response at voltage peaks,
with a typical peak voltage detect time (pVdT) of 1 ms.
o - Sags
are corrected with a peak voltage response time (pVrT) of
1.5 ms–1/10th of a cycle, including detection time.
· Adaptive Frequency Management (aFM) and auto-select of ~50 Hz or ~60 Hz with Advanced Digital Phase Locked Loop Synchronization (PLL)
· True Sinusoidal Reconstruction–tSR
